全流三片式高平台卡箍球阀

·ISO 5211平臺直接安装

·ISO 5211 DIRECT MOUNTING PAD

·防爆中軸BLOW-OUT PROOF STEM

·卡箍式T-CLAMP END

·工作壓力WORKING PRESSURE(CWP):

                   DN8~DN50 1000psi

                   DN65~DN80 800psi

·適用温度範圍TEMPERATURE RANGE:-20 to 180℃

·掛鎖装置 LOCKING DEVICE
